Groundsmaster 4500 --D/4700--D Foldout DrawingsPage 9 - 1

Chapter 9

Foldout Drawings

Table of Contents

ELECTRICAL DRAWING DESIGNATIONS 2.......

HYDRAULIC SCHEMATICS

Groundsmaster 4500-- D 3.....................

Groundsmaster 4500--D with Optional

Flow Divider Kit 4...........................

Groundsmaster 4700-- D 5.....................

Groundsmaster 4700--D with Optional

Flow Divider Kit 6...........................

ELECTRICAL SCHEMATICS

Groundsmaster 4500-- D/4700--D Models 30881

and 30882 7...............................

Groundsmaster 4500-- D/4700--D Models 30873

and 30874 8...............................

Groundsmaster 4500--D/4700--D Operator Cab 9.

WIRE HARNESS DRAWINGS

Main Wire Harness 10.........................

Seat and Console Wire Harness 12.............

PowerCenterWireHarness 14.................

Deck6and7WireHarness

(Groundsmaster 4700--D) 16.................

Engine Wire Harness Models 30881

and 30882 18..............................

Engine Wire Harness Models 30873

and 30874 20..............................

Foldout

Drawings
