Toro 30881 Service Manual

Groundsmaster 4500 --D/4700--DPage 6 -- 2Axles, Planetaries and Brakes
Specifications
Item Specification
Tire pressure (front and rear) 20 psi (138 kPa)
Rear wheel toe--in 0.125in(3mm)
Wheel lug nut torque (front and rear) 85 to 100 ft--lb (116 to 135 N--m)
Steering cylinder bolt torque 100 to 125 ft--lb (136 to 169 N--m)
Planetary wheel drive mounting screw torque 75 to 85 ft--lb (102 to 116 N--m)
Brake housing mounting screw torque 75 to 85 ft--lb (102 to 116 N--m)
Wheel motor mounting screw torque 75 to 85 ft--lb (102 to 116 N--m)
Planetary wheel drive gear drive lubricant SAE 85W--140 wt. gear lube
Planetary gear lube capacity (each wheel) 22 fl oz (0.65 l)
Rear axle lubricant SAE 85W--140 wt. gear lube
Rear axle gear lube capacity 80 fl oz (2.4 l)
Rear axle gear box lubricant SAE 85W--140 wt. gear lube
Rear axle gear box gear lube capacity 16 fl oz (0.5 l)
