Toro 4573 - Stopping the Machine; Using the Bag on Demand; Emptying the Grass Collector

Figure16
1.Tractioncontrolpedal2.Reversespeedpedal
Note:Toincreasethespeed,pushthetraction
controlpedaldown.Todecreasethespeed,release
thepressureonthetractioncontrolpedal.
Togobackward:
1.Releasetheparkingbrake;refertoReleasingthe
ParkingBrake.
2.Placeyourfootonthereversespeedpedaland
slowlypressonthepedaltomovebackward
(Figure16).
Note:Toincreasethespeed,pushthereverse
speedpedaldown.Todecreasethespeed,release
thepressureonthereversespeedpedal.
Important:Toavoidtransmissiondamage,always
releasetheparkingbrakebeforemovingthe
tractioncontrolpedalorthereversespeedpedal.
Important:Topreventdamagetothemower,
alwayssetthemowertothehighestcutting
positionwhenyoudrivethemachineoffthelawn.
StoppingtheMachine
1.Releasethetractioncontrolpedalorreversespeed
pedal.
2.Disengagetheblades(PTO).
TurntheignitionkeytoOff.
3.Settheparkingbrakeifyouleavethemachine
unattended;refertoSettingtheParkingBrake.
Note:Removethekeysfromtheignitionand
KeyChoiceswitches.
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethemachinewhile
itisunattended.
AlwaysremovetheignitionandKeyChoice
keysandsettheparkingbrakewhenleaving
themachineunattended,evenifitisjustfora
fewminutes.
UsingtheBagonDemand
Youcanactivateordeactivatethebagondemand
featurewhilethemachineismowingorisstopped.If
youarebagginggrassthatistallandthick,raisethe
height-of-cutandmowataslowerspeed.
1.Movethebag-on-demandlever(Figure3)forward
tobagthegrassclippings.
2.Movethebag-on-demandleverrearwardtostop
baggingthegrassclippingsandrecyclethem.
EmptyingtheGrassCollector
Whenthecollectorwarninglight(Figure6)comeson
andthebuzzersounds,thegrasscollectorisfulland
mustbeemptied.
Important:Topreventthedischargetunnelfrom
gettingclogged,disengagetheblades(PTO)when
thewarninglightcomesonandthebuzzersounds.
1.Disengagetheblades(PTO)andmovethethrottle
totheSlowposition.
2.Pulloutthetelescopingdumpleverandpush
itforwardanddowntotiltthegrasscollector
(Figure17).
