Toro 4573 - Where to Add Grease; Engine Maintenance; Servicing the Air Cleaner

WheretoAddGrease
Figure19
ItemName
Quantity
(pumps)
Interval(hours)
Lubricant
1
Frontwheel—greasettings
225
Grease
2
Steeringballjoints
450
Oil
3
Steeringsectorgear
150
Grease
4
Steeringpiniongear
125
Grease
5
Steeringshaftbearing
150
Oil
6
Steeringshaftbearing
150
Oil
7
Motionlever—greasetting
150
Grease
8
Shafthubforliftingthemowerhousing
150
Oil
9Motionlinkballjoints450
Oil
10Brakepedalhubs250
Oil
11Parkingbrakering150
Oil
12
Steeringbearing
125
Grease
13
LeftandRightSpindle—greasettings
225
Grease
14Mowerhousinghingedpins6Whenremoved
Grease
15Frontaxlepivotpins2Whenremoved
Grease
16
Frontaxlepivotpins225
Grease
EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every25hours—Servicetheair
cleanerfoamelement.(Serviceit
morefrequentlywhenoperatingthe
machineindustyordirtyconditions.)
Every100hours—Servicetheair
cleanerpaperelement.(Serviceit
morefrequentlywhenoperatingthe
machineindustyordirtyconditions.)
1.Parkthemachineonalevelsurface.
2.Disengagetheblades(PTO).
3.Settheparkingbrake.
4.Stoptheengineandwaitforallmovingpartstostop.
5.Removetheignitionkey.
22
