Routingthebatterycablesimproperlycould
damagethemachineandcables,causing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
8.Lifttherubbercoverupoffthepositive(red)cable.
9.Disconnectthepositive(red)cablefromthebattery
post(Figure29).
10.Removethebatteryholddownrod.
11.Removethebatteryfromthechassis.
InstallingtheBattery
1.Placethebatteryintothechassiswiththebattery
poststowardtherearofthemachine(Figure29).
2.Securethebatteryinthechassiswiththeholddown
rod.
3.Usingtheboltandwingnut,connectthepositive
(red)cabletothepositive(+)batterypost(Figure29).
Slidetherubbercoveroverthebatterypost.
4.Usingtheboltandwingnut,connectthenegative
(black)cabletothenegative(–)batterypost
(Figure29).Slidetherubbercoveroverthebattery
post.
CheckingtheElectrolyteLevel
ServiceInterval:Beforeeachuseordaily
1.Tiptheseatforwardtoseethebattery.
2.Removethellercaps.Iftheelectrolyteisnotup
tothelowerpartofthetube(Figure30),addthe
requiredamountofdistilledwater;refertoAdding
WatertotheBattery.
Figure30
1.FillerCaps
3.Plates
2.Lowerpartofthetube
Batteryelectrolytecontainssulfuricacidwhich
isadeadlypoisonandcausessevereburns.
•Donotdrinkelectrolyteandavoidcontact
withskin,eyesorclothing.Wearsafety
glassestoshieldyoureyesandrubbergloves
toprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryisjust
beforeyouoperatethemachine.Thisletsthewatermix
thoroughlywiththeelectrolytesolution.
1.Cleanthetopofthebatterywithapapertowel.
2.Removethellercaps(Figure30).
3.Slowlypourdistilledwaterintoeachbatterycell
untilthelevelisuptothelowerpartofthetube
(Figure30).
Important:Donotoverllthebattery.
Electrolyte(sulfuricacid)canseverelycorrode
anddamagethechassis.
4.Replacethellercaps.
