HydrostaticDriveBeltInstallation(continued)

4.Connectthebatterybyinstallingthepositivecablerst,thenthenegative

cabletothebattery.

HydrostaticDriveTransmissionReplacement

HydrostaticDriveTransmissionRemoval

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe

engine,waitforallmovingpartstostopandremovethekey.Engagethe

parkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Usinganappropriateliftingdevice,raisetherearofthemachineandsupport.

Note:Donotraiseandsupportonthehydroplate.

4.Removethedeckbelt.DeckBeltReplacement(page6–4)

5.Usinga½inchbreakerbar,insertintothemostaccessiblesquareholeof

theidlerarm.

g346265

Figure77

6.Turnthebreakerbartoreleasebelttension.Removethedrivebeltfrom

theidlerpulley.

7.Removethewheelfromthesidebeingserviced.

8.Releasetheparkingbrake.

9.ZT5400only,removethe2brakereturnspringsconnectingthebrakerodto

thehydroplate.

10.Removethe8(3/8inch)(4perside)locksnutsandboltssecuringthehydro

platetothechassis.Removethehydroplate.

11.Removethelockingcotterpinsecuringthebrakerodtothehydrostatic

transaxle.Removethebreakrodfromthehydrostatictransaxle.

12.Removethe5/16inchnutandshoulderboltsecuringmotioncontrollink

tothehydrostatictransaxle.

13.Removethecartridgelteranddrainthehydrostatictransaxlebeingremoved.

14.Removeandplugthespringclampssecuringthereservoirhosetothe

hydrostatictransaxle.

DriveSystem:ServiceandRepairs

Page7–6

4000SeriesZMASTER®ServiceManual

3442-427RevA
