11.Fine-tunethescrewadjusterbyturningittoget7.6
mm(3inches)height.
Note:Toincreasetheheight,turntheadjuster
screwclockwise;todecreasetheheight,turnit
counterclockwise.
Note:Ifthefrontdecklinksdonothaveenough
adjustmenttoachieveaccuratecutheight,youcan
utilizethesingle-pointadjustmenttogainmore
adjustment.
g017441
Figure78
1.Whizlocknut3.Jamnut
2.Adjusterscrew4.Yoke
12.Toadjustthesingle-pointsystem,loosenthe2boltsat
thebottomoftheheight-of-cutplate(Figure79).
g017442
1
Figure79
1.Boltsatthebottomoftheheight-of-cutplate
13.Ifthedeckistoolow,tightenthesingle-point
adjustmentboltbyrotatingitclockwise.Ifthedeckis
toohigh,loosenthesingle-pointadjustmentboltby
rotatingitcounterclockwise(Figure80).
Note:Loosenortightenthesingle-pointadjustment
boltenoughtomovetheheight-of-cutplatemounting
boltsatleast1/3thelengthoftheavailabletravelin
theirslots.Thisregainssomeupanddownadjustment
oneachofthe4decklinks.
g017036
Figure80
1.Single-pointadjustmentbolt
14.Tightenthe2boltsatthebottomoftheheight-of-cut
plate(Figure79).
Note:Formostconditions,adjustthebackbladetip4
mm(1/4inch)higherthanthefront.
15.Torquethe2boltsto37to45N∙m(27to33ft-lb).
16.Onbothsidesofthedeck,measurefromthelevel
surfacetothebacktipoftheblade(postionB)as
showninFigure77.
Note:Themeasurementshouldread8.3cm(3-1/4
inches)
17.Fine-tunethescrewadjusterbyturningittoget8.3
mm(3-1/4inches)height(Figure78).
Note:Toincreasetheheight,turntheadjustment
nutclockwise;todecreasetheheight,turnit
counterclockwise.
18.Measureuntilall4sidesarethecorrectheight.
19.Tightenallthenutsonthedeck-lift-armassemblies.
20.Lowerthedischargechute.
