Toro 74264TE - Product Overview; Controls; Figure

110-0820
1.Fast
5.Warning—readtheOperator’sManual.
2.Slow6.Poisonandcausticliquid/chemicalburnhazard—keep
childrenasafedistancefromthebattery.
3.Neutral
7.Explosionhazard—nore,openames,orsmoking;avoid
sparks.
4.Reverse8.Tounlockthetractiondrive,turntheby-passvalve1complete
revolutioncounterclockwiseusinga5/8inchor16mm
wrench.
ProductOverview
Figure3
1.Motioncontrollever
6.Controls
2.Parkingbrakelever
7.Seatbelt
3.Height-of-cutlever
8.Rollbar
4.Fuelcap(bothsides)
9.Enginescreen
5.Lift-assistlever
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure3andFigure4).
Figure4
1.Hourmeter6.Throttlecontrol
2.Ignitionswitch
7.PTOSwitch
3.Glowplugswitch
8.Audiblealarm
4.Glowpluglight
9.Fuelselectorvalve
5.EngineTemperaturelight
HourMeter
Thehourmeterrecordsthenumberofhourstheengine
hasoperated.Itoperateswhentheengineisrunning.
Usethesetimesforschedulingregularmaintenance
(Figure4).
GlowPlugLight
Theglowplugindicatorlightturnsonwhentheglow
plugbuttonisengaged(Figure4).
GlowPlugSwitch
Thisswitchactivatestheglowplugsandisindicatedby
theglowpluglight.Holddowntheglowplugswitchfor
10secondspriortostarting.
