Toro 74264TE - Servicing the Engine Oil

Figure33
1.Airlterbody
3.Aircleanercover
2.Airlter
4.Latches
ServicingtheEngineOil
OilType:High-qualitydetergentoilclassiedAPI
ServiceCDorhigherfordieselengines.Donotuse
specialadditiveswithrecommendedoils.
CrankcaseCapacity:3.9quarts(3.7liters)
Viscosity:Seethetablebelow:
Figure34
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Note:Checktheoilwhentheengineiscold.
1.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedpositionandsettheparking
brake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Cleanaroundtheoildipstick(Figure35)sodirt
cannotfallintothellerholeanddamagetheengine.
4.Pulltheoildipstickoutandwipethemetalendclean
(Figure35).
5.Slidetheoildipstickfullyintothellertube.Pullthe
dipstickoutandlookatthemetalend(Figure35).If
theoillevelislow,slowlypouronlyenoughoilinto
thellholetoraisetheleveltothefullmark.
Important:Donotoverllthecrankcasewith
oilbecausethismaycauseenginedamage.Do
notruntheenginewithoilbelowthelowmark
becausetheenginemaybedamagedasaresult.
Figure35
1.Oildipstick3.Rearleftsideofmachine
2.Metalend
ChangingtheEngineOil
ServiceInterval:Aftertherst50hours
33
