Toro Greensmaster
3150 - Chassis; Specifications; General Information; Service and Repairs

Greensmaster 3150 Page 6 -- 1 Chassis
Chapter 6
Chassis
Table of Contents
SPECIFICATIONS 2............................
GENERAL INFORMATION 3.....................
Operator ’s Manual 3..........................
SPECIAL TOOLS 3.............................
SERVICE AND REPAIRS 4......................
Front Wheel and Brakes 4.....................
Rear Wheel (2WD) 6..........................
Rear Wheel (Optional 3WD) 8..................
Rear Wheel Hub and Motor Assembly
(Optional 3WD) 10..........................
Rear Castor Fork 12..........................
Cutting Unit Pull Frame 14.....................
Chassis
