ServiceandRepairs

ServicingtheBrake

g225901

Figure196

1.Brakecablelink

7.Returnspring(right)

13.Adjusterspring

2.Brakereturnspring

8.Starwheelsocket

14.Brakeleverretainer

3.Cotterpin9.Starwheeladjuster15.Returnspring(left)

4.Clevispin

10.Pivotnut16.Brakespider

5.Brakecable11.Brakeshoeset17.Brakelever

6.Dustshield12.Brakedrum

DisassemblingtheBrake

1.Parkthemachineonalevelsurface,lowerthecuttingdeck,shutoffthe

engine,settheparkingbrake,andremovethekeyfromthekeyswitch.

2.Removethewheelassemblyfromthefrontaxle;refertoRemovingthe

Wheel(page7–4).

3.Removethebrakereturnspring(item2inFigure196)fromthebrakecable

link.Removethecotterpinandclevispin,anddisconnectthebrakecable

fromthebrakelever.

Note:Ifthebrakedrumisseverelyworn,itmaybenecessarytoloosenthe

brakeshoesbeforeremovingthebrakedrum.Loosenthebrakeshoesby

turningthestarwheeladjusterinsidethebrakedrumassembly.

4.Pullthebrakedrumfromthemachine.

5.Inspectthebrakingsurfaceofthebrakedrum.Ifthereisexcessivewear

orscoring,replacethebrakedrum.

CAUTION

Thespringsareundertensionandcouldpossiblyslipduring

removal.

Becarefulwhenremovingtheadjusterandbrakereturnsprings.

DriveAxles:ServiceandRepairs

Page8–6

Groundsmaster

3280-D/3320

05138SLRevB
