ProductOverview
Controls
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
g196908
Figure3
1.Brakepedals3.Tractionpedal
2.Pedal-lockinglatch4.Tilt-steeringlever
TractionPedal
Tostopthemachine,reduceyourfootpressureon
thetractionpedalandallowittoreturntothecenter
position(Figure3).
BrakePedals
Thereare2footpedalsthatoperateindividualwheel
brakesforturningassistance,parking,andtoaidin
betterside-hilltraction.Alatchconnectsthepedals
forparking-brakeoperationandtransport(Figure3).
Pedal-LockingLatch
Thepedal-lockinglatchconnectsthepedalstogether
toengagetheparkingbrake(Figure3).
Tilt-SteeringLever
Pressthetilt-steeringleverdowntotiltthesteering
wheeltothedesiredposition,thenreleasethelever
tolocktheadjustment(Figure3).
Parking-BrakeLatch
Aknobontheleftsideoftheconsoleactuatesthe
parking-brakelock(Figure3).
Toengagetheparkingbrake,connectthepedalswith
thelockinglatch,pushdownonbothpedals,andpull
theparking-brakelatchout.T oreleasetheparking
brake,pressbothpedalsuntiltheparking-brakelatch
retracts.
Hazard-LightSwitch
Pressthehazard-lightswitchtoactivatethehazard
lights(Figure3).
Turn-SignalSwitch
Presstheleftsideoftheturn-signalswitchtoactivate
theleft-turnsignalandtherightsideoftheswitchto
activatetheright-turnsignal(Figure3).
KeySwitch
Thekeyswitch(Figure4)has3positions:OFF,
ON/PREHEAT,andSTART.
g028453
1
2
3
4
5
6
7
g028453
Figure4
1.Liftswitches
5.Hi—Lospeedcontrol
2.PTOswitch
6.Engine-speedswitch
3.Keyswitch
7.Lightswitch(optional)
4.InfoCenter
Engine-SpeedSwitch
Theengine-speedswitchhas2modestochangethe
enginespeed(Figure4).
Bymomentarilytappingtheswitch,theengine
speedcanbeincreasedordecreasedin100-rpm
increments.Byholdingtheswitchdowntheenginewill
automaticallymovetoHIGHorLOWIDLE,depending
onwhichswitchisdepressed.
PTOSwitch
ThePTOswitchhas2positions:OUT(START)and
IN(STOP).PullthePTObuttonouttoengagethe
mower-deckblades.Pushthebuttonintodisengage
themower-deckblades(Figure4).
16
