CabControls
g032672
Figure7
1.Air-conditioningswitch4.Temperaturecontrol
2.Air-recirculationcontrol5.Windshield-wiperswitch
3.Fancontrol
6.Blankswitchesforoptional
kits
Air-RecirculationControl
Theair-recirculationcontrolsetsthecabtoeither
recirculatetheairinthecabinortodrawairintothe
cabinfromoutside(Figure7).
•Setittorecirculatetheairwhenusingthe
air-conditioning.
•Setittodrawairinwhenusingtheheaterorfan.
FanControl
Rotatethefancontrolknobtoregulatethespeedof
thefan(Figure7).
TemperatureControl
Rotatethetemperaturecontrolknobtoregulatethe
airtemperatureinthecab(Figure7).
Windshield-WiperSwitch
Usethisswitchtoturnthewindshieldwipersonor
off(Figure7).
AirConditioningSwitch
Usethisswitchtoturntheairconditioningonoroff
(Figure7).
WindshieldLatch
Liftupthelatchestoopenthewindshield(Figure8).
Pressinthelatchtolockthewindshieldopen.Pull
outanddownonthelatchtocloseandsecurethe
windshield.
g196911
Figure8
1.Windshieldlatch
RearWindowLatch
Liftupthelatchestoopentherearwindow.Pressin
thelatchtolockthewindowopen.Pulloutanddown
onthelatchtocloseandsecurethewindow(Figure8).
Important:Youmustclosetherearwindow
beforeyouopenthehood;otherwise,damage
mayoccur.
