Toro Groundsmaster 4100 - Hauling the Machine; Locating the Tie-Down Points

Therearejackingpointslocatedatthefrontandrear
ofthemachine.
•Ontheframeattheinsideofeachfrontdrivetire
•Atthecenteroftherearaxle
HaulingtheMachine
•Removethekeyandshutoffthefuel(ifequipped)
beforestoringortransportingthemachine.
•Usecarewhenloadingorunloadingthemachine
intoatraileroratruck.
•Usefull-widthrampsforloadingthemachineinto
atraileroratruck.
•Tiethemachinedownsecurely.
LocatingtheTie-Down
Points
Therearetiedownslocatedatthefrontandrearsides
ofthemachine(Figure71).
Note:Useproperly-ratedDOT-approvedstrapsin4
cornerstotiedownthemachine.
•2onthefrontoftheoperator'splatform
•Rearbumper
g203193
Figure71
1.Reartie-downpoint2.Fronttie-downpoints
