g020680
Figure105
1.Drainplug2.Brakehousing
4.Whenalloftheoilhasdrainedfromboth
locations,installthepluginthebrakehousing.
5.Rotatethewheeluntiltheopenplugholeinthe
planetaryisatthe12o'clockposition.
6.Throughtheopenhole,slowlylltheplanetary
with0.65L(22oz)ofhighqualitySAE
85W-140wtgearlube.
Important:Iftheplanetaryllsbeforethe
0.65L(22oz)ofoilisadded,wait1hour
orinstalltheplugandmovethemachine
approximately3m(10ft)todistributetheoil
throughthebrakesystem.Then,removethe
plugandaddtheremainingoil.
7.Installtheplug.
8.Repeattheprocedureontheopposite
planetary/brakeassembly.
CheckingtheRear-Axle
Lubricant
ServiceInterval:Every400hours
TherearaxleislledwithSAE85W-140gearlube.
Checkthelubricantlevelbeforeyourststartthe
engineandasrecommended.Thecapacityis2.4L
(80oz).Visuallyinspectforleaksdaily.
1.Positionthemachineonalevelsurface.
2.Removeacheckplugfromtheendoftheaxle
andensurethatthelubricantisuptothebottom
ofthehole(Figure106).
Note:Ifthelevelislow,removethellplugand
addenoughlubricanttobringtheleveluptothe
bottomofthecheck-plugholes.
g011487
Figure106
1.Checkplug
2.Fillplug
Checkingthe
Rear-Axle-Gearbox
Lubricant
ServiceInterval:Every400hours
ThegearboxislledwithSAE85W-140gearlube.
Thecapacityis0.5L(16oz).Visuallyinspectfor
leaksdaily.
1.Positionthemachineonalevelsurface.
2.Removethecheck/llplugfromtheleftsideof
thegearboxandensurethatlubricantisupto
thebottomofthehole(Figure107).
Note:Ifthelevelislow,addenoughlubricantto
bringtheleveluptothebottomofthehole.
g011488
Figure107
1.Gearbox2.Check/llplug
71
