5.Connectthehosettings.
6.Useahoistorhave2peopleholdupthehopper
andremovethecylinderlock.
7.Carefullylowerthehoppertothemachineframe.
RaisingtheHopperwithout
Power
1.Raisethemachineandsupportitusingjack
standsratedfortheweightofthemachine;refer
toSpecications(page9).
2.Placealargedrainpanunderthehopperlift
cylinder(Figure13).
g322674
Figure13
Hopperliftcylinder
3.Removethehydraulichosefromthebarrelend
oftheliftcylinderandallowtheuidtodraininto
thepan.
4.Useahoistorhave2peopleholdupthehopper
andinstallthecylinderlock.
5.Aftermakingrepairs,installthehosetothe
cylinder,thencheckthehydraulic-uidlevel;
adduidifnecessary.RefertoCheckingthe
Hydraulic-FluidLevelfortheLiftandSlew
System(page36).
MovingaNon-Functional
Machine
Important:Donottoworpullthemachinewithout
rstopeningthebypassvalvesinthisprocedure,
oryouwilldamagethehydraulicsystem.
Note:Openingthebypassvalveswilleasemoving
themachine,butthetracksmaystillskidduetotheir
lengthandresistance.
1.Ifpossible,raisethehopperandinstallthe
cylinderlock;refertoUsingtheCylinderLock
(page20).
2.Shutofftheengineandremovethekey.
3.Usingawrench,turnthebypassvalveontheleft
andrighttransaxlessothattheatsidesofthe
valvefaceleftandright(T owposition)asshown
inFigure14andFigure15.
g288601
Figure14
1.Bypassvalve
g288600
Figure15
1.Towposition2.Driveposition
4.Towthemachineasrequired.
5.Afterrepairingthemachine,turnthebypass
valvessothattheatsidesfaceupanddown
(Driveposition)asshowninFigure15.
6.Removethecylinderlockandlowerthehopper.
16
