Toro MB TX 2500S - Servicing the Foam Element; Servicing the Paper Element; Installing the Elements; Checking the Engine-Oil Level

g028106
Figure24
1.Air-cleanercover3.Paperelement
2.Foamelement
ServicingtheFoamElement
1.Washthefoamelementinwarmwaterand
detergent.
2.Rinseandallowittoairdry.
3.Lightlyoilthefoamelementwithnewoiland
squeezeoutexcessoil.
ServicingthePaperElement
1.Gentlytapthepaperelementtodislodgedirt.
Note:Donotwashthepaperelementoruse
pressurizedair,asthisdamagestheelement.
Note:Replaceadirty,bent,ordamaged
element.Handlethenewelementcarefully;
donotuseifthesealingsurfacesarebentor
damaged.
2.Cleantheair-cleanerbaseasrequired,and
checkthecondition.
InstallingtheElements
1.Installthefoamelementontothepaperelement.
2.Installtheelementsontotheair-cleanerbase
(Figure24).
3.Installthecover,andsecureitwiththelatches
(Figure23).
CheckingtheEngine-Oil
Level
ServiceInterval:Beforeeachuseordaily
Important:Remembertoadd80%oftheoil,
andthengraduallyllittotheFullmarkonthe
dipstick.
Important:Donotruntheenginewiththeoil
levelabovetheFullmarkorbelowthelowmark.
Otherwise,youmaydamagetheengine.
1.Parkthemachineonalevelsurface,move
themotion-controlleverstotheNEUTRAL-LOCK
position,engagetheparkingbrake,andlower
thehopper.
2.Shutofftheengine,andremovethekey.Allow
theenginetocool.
3.Openthecowl.
4.Checktheengine-oillevelasshowninFigure
25.
g243578
Figure25
22
