8.Inspecttheconditionofthewheels.Ifthewheels
showsignsofwear,replacethematthistime.
9.Beginningatthedrivesprocket,coilthenew
trackaroundthesprocket,ensuringthatthe
lugsonthetracktbetweenthespacersonthe
sprocket(Figure41).
10.Pushthetrackunderthelugsandbetweenthe
roadwheels(Figure41).
11.Startingatthebottomofthefrontwheel,install
thetrackaroundthewheelbyrotatingthetrack
rearwardwhilepushingthelugsintothewheel.
12.Tensionthetrack;refertoAdjustingtheTrack
Tension(page30).
13.Lowerthemachinetotheground.
14.Repeatsteps3through13toreplacetheother
track.
ServicingtheDriveBelt
InspectingtheDriveBelt
ServiceInterval:Every100hours
1.Parkthemachineonalevelsurface,move
themotion-controlleverstotheNEUTRAL-LOCK
position,engagetheparkingbrake,andlower
thehopper.
2.Shutofftheengine,andremovethekey.Allow
theenginetocool.
3.Releasethecushionandremovethefueltank;
refertoReleasingtheCushionforRearAccess
(page19).
4.Inspectthebelt(Figure42).Replacethebelt
ifitisworn;refertoReplacingtheDriveBelt
(page31).
Note:Thesignsofawornbeltinclude
squealingwhilethebeltisrotating,frayededges,
burnmarks,andcracksonthebelt.
g189546
Figure42
1.Extensionspring2.Belt
ReplacingtheDriveBelt
ServiceInterval:Every300hours
1.Parkthemachineonalevelsurface,move
themotion-controlleverstotheNEUTRAL-LOCK
position,engagetheparkingbrake,andlower
thehopper.
2.Shutofftheengine,andremovethekey.Allow
theenginetocool.
3.Releasethecushionandremovethefueltank;
refertoRemovingtheFuelT ank(page27).
4.Raisetherearofthemachineandsupportthe
machineonjackstands.
5.Removetheskidplate(Figure43).
g325648
Figure43
1.Rearbolt(2)3.Sidebolt(4)
2.Skidplate
6.Removetheextensionspring(Figure42).
7.Removethe2boltsand2nutsandloosenthe
2setscrewsonthecoupler.Removethegear
pumpfromthepumpmount(Figure44).
Note:Youdonotneedtoremovethettings
fromthepump.
31
