Toro TimeMaster 20200 - Recycling the Clippings; Bagging the Clippings

RecyclingtheClippings
Thismachinecomesfromthefactoryreadytorecyclegrass
andleafclippingsbackintothelawn.Topreparethemachine
torecycle,dothefollowing:
•Iftheside-dischargechuteisonthemachine,remove
itandlowertheside-dischargedeector;referto
RemovingtheSide-dischargeChute(page14).
•Ifthegrassbagisonthemachine,removeit;referto
RemovingtheGrassBag(page13).
•Iftherear-dischargeplugisnotinstalled,gripitbythe
handle,raisethereardeector,andinsertitintothe
rear-dischargechuteuntilthelatchlocksintoplace;refer
toFigure24.
1
2
G016490
3
Figure24
1.Reardeector
3.Therear-dischargeplug
installed
2.Inserttherear-discharge
plug
WARNING
Ensurethattherear-dischargeplugisinplace
beforeyourecycletheclippings.Neverengagethe
bladeswithouteithertherear-dischargeplugorthe
grassbaginstalled.
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesandother
similardebristobethrowntowardtheoperatoror
bystandersandresultinseriouspersonalinjuryor
death.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
Iftheside-dischargechuteisonthemower,
removeitbeforebaggingtheclippings;referto
RemovingtheSide-dischargeChute(page14).
InstallingtheGrassBag
1.Raiseandholdupthereardeector(Figure25).
1
2
G017408
3
Figure25
1.Reardeector
3.Latch
2.Rear-dischargeplug
2.Removetherear-dischargeplugbypullingdownonthe
latchwithyourthumbandpullingtheplugoutfrom
themachine(Figure25).
3.Installthebagrodintothenotchesatthebaseofthe
handleandrockthebagbackandforthtoensurethat
therodisseatedatthebottomofbothnotches;refer
toFigure26.
G016513
1
2
Figure26
1.Bagrod
2.Notch(2)
4.Lowerthereardeectoruntilitrestsonthegrassbag.
RemovingtheGrassBag
Toremovethebag,reversethestepsin
InstallingtheGrassBag(page13).
13
