Toro TimeMaster 20200 - Checking for Bent Blades; Blade Removal and Installation

CheckingforBentBlades
1.RotatethebladestothepositionshowninFigure42.
B
B
2
1
3
g016532
Figure42
1.Frontofcuttingdeck3.Measurefromthecutting
edgetoasmooth,level
surface
2.MeasureatlocationsA
andB
2.Measurefromalevelsurfacetothecuttingedges
atlocationsAandB(Figure42),andrecordboth
dimensions.
3.Rotatethebladessothattheiroppositeendsareat
locationsAandB(Figure42).
4.Repeatthemeasurementsinstep2andrecordthem.
Note:IfthedifferencebetweenthedimensionsA
andBobtainedinsteps2and4exceeds1/8in(3
mm),thebladeisbentandyouwillneedtoreplace
it.RefertoRemovingtheBlades(page21)and
InstallingtheBlades(page22).
WARNING
Abladethatisbentordamagedcouldbreakapart
andcouldseriouslyinjureorkillyouorbystanders.
•Alwaysreplaceabentordamagedbladewith
anewblade.
•Neverleorcreatesharpnotchesintheedges
orsurfacesofablade.
RemovingtheBlades
Replacethebladeswhenthemachinehitsasolidobjector
whenabladeisoutofbalanceorbent.Useonlygenuine
Tororeplacementblades.
1.Useablockofwoodtoholdeachbladesteadyandturn
thebladeboltcounterclockwiseasshowninFigure43.
Figure43
2.RemoveeachbladeasshowninFigure44.
G016530
1
2
3
4
Figure44
1.Spindle(2)3.Blade(2)
2.Bladedriver(2)4.Bladebolt(2)
3.Inspectthepinsonthebladedriversforwearand
damage.
21
