5
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use the chart below to verify all parts have been shipped.
Important This kit and bagger will require significant time to install the first time. A right angle drill is recommended
for installation.
Step Description Qty. Use
1
No parts needed Removing the existing mower cover
2
No parts needed
Removing the anti-scalp roller and
bracket
3
Anti-scalp roller bracket
Tapping screw, 3/8 x 1 inch
1
1
Installing the anti-scalp roller and
bracket
4
Mounting plate
Bolt, 3/8 x 1-1/4 inch
Flange nuts, 3/8 inch
1
2
2
Installing the mounting plate
5
Pulley assembly 1 Installing the pulley assembly
6
No parts needed
Removing the drive wheels and bumper
guard
7
Bagger mounting bracket
Left side bagger bracket
Right side bagger bracket
Bolt, 3/8 x 1 inch
Flange nut, 3/8 inch
Belleville washer, 3/8 inch
1
1
1
10
10
8
Installing the bagger brackets
8
Hood assembly
Bag
Clevis pin
Hairpin cotter
1
2
2
2
Installing the hood assembly and bags
9
Blower assembly 1 Installing the blower assembly
10
Blower belt cover
Bagger Belt
Idler spring
Pulley cover
1
1
1
1
Installing the bagger belt and idler
spring
