Toro Workman MD Operator's Manual

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Steeringwheel
1
Installthesteeringwheel(Models
07266TCand07273TC).
2
Nopartsrequired
–
Checktheuidlevelsandtireair
pressure.
Operator'sManual
1
Engineowner'smanual1
PartsCatalog
1
Safetytrainingmaterial
1
RegistrationCard
1
PredeliveryInspectionForm1
CerticateofQuality
1
3
Key2
ReadtheOperator'sManualandview
thetrainingmaterialbeforeoperating
themachine.
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
1
InstallingtheSteering
Wheel(Models07266TC
and07273TC)
Partsneededforthisprocedure:
1
Steeringwheel
Procedure
1.Throughtheopeningsinthebackofthesteering
wheel,releasethelocktabsofthecentercoverand
removethecoverfromthewheel(Figure3).
Figure3
1.Steeringshaft
5.Washer
2.Dustcover6.Locknut
3.Steeringwheel7.Centercover
4.Tabslotsinwheel
8.Opening(foraccesstothe
steeringwheeltabs)
2.Removethelocknutandwasherfromthesteeringshaft
(Figure3).
3.Alignthesteeringwheelontothesplinesofthesteering
shaft(Figure3).
Note:Positionthesteeringwheelontheshaft
sothatwhenthetiresofthemachinearepointed
straightahead,thecrossbeamofthesteeringwheelis
horizontalandthethickerspokeofthesteeringwheel
ispointingdown.
4.Assemblethewasherandlocknutthreadsofthe
steeringshaft(Figure3).
5.Torquethelocknutto24-29N-m(18-22ft-lb).
11
