31
Data Transmission
IrDA
1. Place the printer close to the host so that their IrDA
windows face each other within 20 cm distance.
2. Turn on the printer and the host, and send data
from the host to the printer.
NOTE:
While communicating, avoid location where the IrDA
window is subjected to direct sunlight. A
communication failure may occur.
To communicate with the host via IrDA, it is
required to configure the printer settings on the
host.
Communicable distance and angle is shown in the
figure on the right. Note that this performance is
obtained under 1000 lux or less of fluorescent
lamp light.
USB
1. Turn on the host and start the system.
2. Turn on the printer and connect a USB cable to the
printer.
3. Connect the USB cable to the host.
4. Send data from the host to the printer.
NOTE:
For details of the interface cable, please consult
the nearest TOSHIBA TEC representative.
When disconnecting the USB cable, please follow
the instruction of the system on the host.
When connecting a USB cable or an RS232C cable to the printer, put the ferrite core supplied with the
printer on the cable, as shown below.
Printer
Ferrite Core
Approx. 20 mm
Host
Wind the cable around
the ferrite core one time.
Max. 20cm
Host
PC
Handy Terminal
Printer
USB Cable
USB Port
