Toshiba B-EV4T SERIES - Interior

1. PRODUCT OVERVIEW ENGLISH VERSION EO1-33087
1.5 Appearance
E1- 4
1.5.4 Interior
WARNING!
Do not touch the print head or
around it just after printing.
You may get burned as the
p
rint head becomes very hot
during printing.
Ribbon Rewind Gea
r
Media Guide
Media Holder Lock Switch
Black Mark Senso
r
Cover Open Senso
r
Feed Gap Senso
r
(Receiver)
Media Guide
Adjustment Dial
Print Head
Media Holde
r
Top Cover
Platen
Spring Guide Wheel (Take-up side)
Spring Guide Wheel (Supply side)
Feed Gap Sensor (Transmitter)
Ribbon Access Cover
