1.5 Appearance
E1- 3
1.5 Appearance
1.5.1 Dimensions
1.5.2 Front View
1.5.3 Rear View
The names of the parts or units introduced in this section are used in the
following chapters.
Dimensions in mm (inches)
Power Jack
Power Switch
Fanfold Paper Slot
Parallel Interface
Connector (Centronics)
USB Interface
Connecto
r
Serial Interface
Connector
(RS-232C)
198 (7.8)
258
(
10.2
)
173
(6.8)
Top Cover
Release Button
FEED Button
Media Outle
t
STATUS Lam
p
Ribbon Access Cover
Media View Window
Ethernet Interface
SD Card Slot
