34
Appendix A
Specifications
Specifications
This section summarizes the dynadock™ U3.0 technical specifications.*
Physical dimensions
Environmental requirements
Power requirements
Weight Approx. 530g/18.7 ounces (including the Base)
Size 47(w) x 77(d) x 223(h) mm (1.8(w) x 3.0(d) x 8.8(h) in.)
(not including the parts that extend beyond the main body)
113.8(w) x 130(d) x 235(h) mm (4.5(w) x 5.1(d) x 9.2(h) in.)
(including the Base)
Conditions Ambient temperature Relative humidity
Operating 5 to 35 °C (41 to 95 °F) 20 to 80%
Non-operating -20 to 55 °C (-4 to 131 °F) 10 to 95%
Thermal Gradient 20 °C (68 °F) per hour maximum
Wet-bulb Temperature 26 °C (78.8 °F) maximum
AC adaptor 100-240 volts AC
50-60 Hz (cycles per second)
dynadock™ 19V DC
2.37 amperes
