DISASSEMBLY INSTRUCTIONS
B1-3
Deflection PCB
1
1
Bottom Plate
2
2
2
1-8: DEFLECTION PCB (Refer to Fig. 1-8)
1.
2.
3.
Remove the 2 screws 1.
Remove the 3 screws 2.
Remove the Deflection PCB in the direction of arrow.
Fig. 1-8
