- 20 -
4-8. Outdoor Unit (RAS-10UA-E3)
No. Parts name Type Specifications
Output (Rated) 750 W, 2 poles, 1 phase, 220 - 240 V, 50Hz
1 Compressor PH102T1-4CH Winding resistance (W) C-R C-S
(at 20°C) 3.17 5.18
Output (Rated) 20 W, 6 poles, 1 phase, 220 - 240 V, 50Hz
2 Fan motor (for outdoor)
HF-240-20B or
Winding resistance (W) Red-Black White-Black
(at 20°C)
387.3 or 235.2
466.2 or 260.1
3
Running capacitor
DS451155BPQC AC 450 V, 1.5 F
(for fan motor)
4
Running capacitor
DS371256CPNB AC 370 V, 25 F
(for compressor)
4-7. Outdoor Unit (RAS-13UAX3, RAS-12UAX3)
No. Parts name Type Specifications
Output (Rated) 1100 W, 2 poles, 1 phase, 220 - 240 V, 50Hz
1 Compressor Winding resistance (W) C-R C-S
(at 20°C) 2.35 3.22
Output (Rated) 30 W, 6 poles, 1 phase, 220 - 240 V, 50Hz
2 Fan motor (for outdoor) HF-240-30B Winding resistance (W) Red-Black White-Black
(at 20°C) 245 388
3
Running capacitor
DS451155BPQC AC 450 V, 1.5 F
(for fan motor)
4
Running capacitor
DS371356CPNB AC 370 V, 35 F
(for compressor)
m
m
m
m
PH225X2C-4FT
FILE NO. SVM-04004
SKF-240-20B
