Toshiba RAS-10KHP-E3 - 4-9. Outdoor Unit Electrical Parts (RAS-07 UAX3); 4-10. Outdoor Unit Electrical Parts (RAS-07 UA-E3)

− 21 −
4-9. Outdoor Unit (RAS-07UAX3)
No. Parts name Type Specifications
Output (Rated) 560W, 2poles, 1 phase, 220 − 240V, 50Hz
1 Compressor PH80T1-4C Winding resistance (Ω) C-R C-S
(at 20°C) 4.80 8.37
Output (Rated) 20W, 6poles, 1 phase, 220 − 240V, 50Hz
2 Fan motor (for outdoor)
HF-240-20B or
SKF-240-20B
Winding resistance (Ω) Red-Black White-Black
(at 20°C) 387.3 or 235.2 466.2 or 260.1
3
Running capacitor
DS451155CBPQC AC 450V, 1.5µF
(for fan motor)
4
Running capacitor
DS371156CPNB AC 370V, 15µF
(for compressor)
5 Overload relay JMRA99208-9201 U/T: 4.2A (80°C), OPEN: 135±5°C, CLOSE: 69±11°C
No. Parts name Type Specifications
Output (Rated) 560W, 2poles, 1 phase, 220 − 240V, 50Hz
1 Compressor PH80T1-4C Winding resistance (Ω) C-R C-S
(at 20°C) 4.80 8.37
Output (Rated) 20W, 6poles, 1 phase, 220 − 240V, 50Hz
2 Fan motor (for outdoor) Winding resistance (Ω) Red-Black White-Black
(at 20°C)
3
Running capacitor
DS451155CBPQC AC 450V, 1.5µF
(for fan motor)
4
Running capacitor
DS371156CPNB AC 370V, 15µF
(for compressor)
5 Overload relay LAAO00A U/T: 9.0A (80°C), OPEN: 135±5°C, CLOSE: 75±11°C
4-10. Outdoor Unit (RAS-07UA-E3)
FILE NO. SVM-04004
HF-240-20B or
SKF-240-20B
387.3 or 235.2 466.2 or 260.1
