Toshiba RAS-10KHP-E3 - Exploded Views and Parts List; 11-1. Indoor Unit Exploded View (Heat Pump Model)

- 76 -
FILE NO. SVM-04004
11. EXPLODED VIEWS AND PARTS LIST
11-1. Indoor Unit (E-Parts Assy)
411
Location Part
Description
No. No.
401 43T60001 Terminal Block, 2P
403
43T69004 TC Sensor
10kΩ 25°C
404
43T69005
Sensor, Thermostat 10kΩ 25°C
405
43T69079
P.C. Board ASSY, WRS-LED
MCC-861
Location Part
Description
No. No.
406
43T69364
Fuse, Temperature, 73°C
410 43T62003 Cord Clamp
43T69384 P.C. Board (RAS-10UKHP-E3)
P.C. Board (RAS-13UKHP-E3)
43T69385
P.C. Board (RAS-07UKHP-E3)43T69383
411
411
(For Heat pump model)
402 43T60002 Terminal Block, 3P
