Media Application Server Installation
2U MAS Physical Specifications
1-2 STRATA CIX MAS INSTALLATION 06/09
2U MAS Physical Specifications
This 2U MAS platform includes the following features and options;
• Intel Pentium® 4, 2.3 gigahertz CPU
• 512 MB memory
• Internal PCI slots – Two full PCI slots for installation of fax modem boards
• Front cable connections
• RoHS Compliant (Restricted use of Hazardous Substances Directive)
Supports Toshiba’s mandate of environmental responsibility.
Basic 2U MAS Specifications
2U MAS Physical Installation
The MAS can be mounted in a two post rack or it can be mounted on sliding rails in a four post
rack.
Two Post Rack Mount
Use four screws to secure the MAS in a standard 19 inch rack. The rack and other equipment must
not block the air-flow at the back and front of the MAS. The rail kit is not intended for use in a two
post rack.
Dimensions of Cabinet
Height: 3.5 inches (86 mm)
Width: 17 inches (430 mm) with bracket: 19 inches (483 mm)
Depth: 18 inches (457.5 mm)
Cabinet Weight Approximately 30 lbs. (13.6 kg)
Installation Type Rack-mountable only. Cannot be floor or wall mounted.
