Media Application Server Installation
Install Fax-modem Board Software - All MAS Systems
Strata CIX MAS Installation 06/09 1-21
5. Click Finish to complete
installation of one fax-
modem card.
If another modem is
detected a Hardward
Installation dialog box
will open. Select
Continue Anayway.
Each modem port must
be installed. The system
treats each port as a
separate device.
Repeat the above steps
for each modem port.
Installing Fax Modem Boards using the Control Panel
1. Click Start > Control Panel.
2. Click on “Phone and Modem Options” icon (shown below).
3. Enter the "Area code" for the installation (This is not used by SES. Windows requires this
entry).
4. Leave the other fields blank and click "OK".
