Media Application Server Installation
Hardware Specifications
1-8 STRATA CIX MAS INSTALLATION 06/09
Hardware Specifications
Part Numbers
For this new platform there are six new part numbers from which to choose.
Hardware Specification
CPU Pentium Dual Core, 1.8 Gigahertz
Memory 1 GB (Maximum 4 GB)
Memory Slots 4 DIMM (DDR2 667/800 MHz)
Hard Drive 80 GB Serial ATA
SATA DVD Drive Serial ATA Combo Drive CD, CD/RW, DVD-ROM
PCI Slots 2 Full length (Note: RAID 5 chassis support one PCI slot.)
USB 2 Ports – Front side connection
Serial I/O 1 Port – Front side connection
Chassis 2U rack mount chassis
Dimensions (HxWxD) 3.47" x 17.32" x 20" (8.814 cm x 44 cm x 50.8 cm)
Environment
Operating temperature: 32° ~ 122° F (0° ~ 50° C)
Humidity: 5% ~ 95% non-condensing
Fans 2 fixed rear fans, 1 hard drive chamber fan
Power Supply 350 Watts
Part Numbers Description
MAS-2U-XPPRO-R3
2U MAS with Windows XP Professional, one 80GB SATA hard drive,
Dialogic HMP 3.0, 1 gigabyte RAM
MAS-2U-R3-RAID1
2U MAS with Windows XP Professional, two 80GB SATA hard drives
(RAID 1 redundancy), Dialogic HMP 3.0, 1 gigabyte RAM
MAS-2U-R3-RAID5
2U MAS with Windows XP Professional, three 73GB SAS hard drives
(RAID 5 redundancy), Dialogic HMP 3.0, 1 gigabyte RAM
MAS-2USVR2K3-R3*
2U MAS with Windows 2003 Server, one 80GB SATA hard drive, Dialogic
HMP 3.0, 1 gigabyte RAM
MAS-2USR3-RAID1*
2U MAS with Windows Server 2003, two 80GB SATA hard drives (RAID 1
redundancy), factory equipped with Dialogic HMP 3.0, 1 gigabyte RAM
MAS-2USR3-RAID5*
2U MAS with Windows Server 2003, three 73GB SAS hard drives (RAID
5 redundancy), Dialogic HMP 3.0, 1 gigabyte RAM
MAS-R3-REDUN-PS Optional dual redundant power supply
*MAS units equipped with Windows Server 2003 are special order items. Please allow three to four
business weeks for delivery.
