Toshiba TOSVERT-130G2+ User Manual

TOSHIBA
4.1 Simple Connection Diagrams (Cont'd)
4 - 2
TOSVERT-130G2+
STANDARD CONNECTION
MODEL 4015 TO 4080
MCCB
DBR
L2(S)
L1(R)
L3(T)
PB
PA
OH
OV
POWER
SUPPLY
400VAC, 50Hz
380-460VAC, 60Hz
RST
F
R
ST
CC
FORWARD DRIVE
REVERSE DRIVE
INTERLOCK
DRIVE
SS1
JOG/SS2
AD2/SS3
MULTI-FUNCTION
SIGNAL INPUT
ANALOG INPUT
HAND
AUTO
PP
RR
CC
FRH
-
+
DIGITAL
OPERATION PANEL
P24
CC
MULTI-FUNCTION
SIGNAL OUTPUT
Ry Ry
+24Vdc
AM
FM
+
+
AM
FM
FAULT
M
M
MAX.
50mA EACH
100mA TOTAL
IV
GND(E)
FLC
FLA
FLB
T1(U)
T2(V)
T3(W)
LOW/LL
RCH/UL
AUTO
REFERENCE
RESET
OUTPUT FREQUENCY SIGNAL
OUTPUT CURRENT SIGNAL
NORMALLY OPEN EXTERNAL
FAULT SIGNAL INPUT
FAULT SIGNAL OUTPUT
FULL SCALE AT 1mA
