TOSHIBA
Pattern run activation 0: Off 0 8-28
mode 1: Terminal operation
2: Touch pad operation
3: Computer communication
Time unit 0: Seconds 0 8-28
1: Minutes
Cycle times 0 to 255 0 8-28
(255: Infinity operating)
Function Function Adjustment Factory Error Ref.
No. Name Display Range Unit Set Message Page
5.6 Programmable Run Patterns
Sr1
Sr2
Pattern 3 (DEC #1 or #2)
Sr4
Time
Sr5
Pattern 5Pattern 4Pattern 3Pattern 2Pattern 1
Sr3
Pattern 1 (ACC #1 of #2)
Pattern 2 (ACC #1 or #2)
Pattern 3 (ACC #1 or #2)
Pattern 4 (DEC #1 or #2)
Pattern 5 (ACC #1 or #2)
Pattern 5 (DEC #1 or #2)
Pt.2
Pt.4
Pt.5
Pt.1t Pt.2t Pt.3t
Pt.4t
Pt.5t
Pt.1
Pt.3
Pt.3
· Up to 7 different preset speed patterns can be automatically executed to produce
what is known as a Pattern Run.
· Each speed can be set to operate in the range of 0 to 8000 seconds or minutes.
· Each pattern can be set to accelerate/decelerate using either one of the two
acceleration/deceleration functions.
· Each pattern can be set to operate in either the forward or reverse direction.
. Pattern may be repeated 0 to 254 times or repeat infinitely.
1st speed LL to UL setting value Hz 0 8-23
2nd speed LL to UL setting value Hz 0 8-23
6 3rd speed LL to UL setting value Hz 0 8-23
6th speed LL to UL setting value Hz 0 8-23
7th speed LL to UL setting value Hz 0 8-23
5th speed LL to UL setting value Hz 0 8-23
4th speed LL to UL setting value Hz 0 8-23
5 - 7
2ND Pattern drive time 0 to 8000 sec 0 8-28
8 #1 to 7 to min
Pattern drive characteristics 0: Forward run, #1 ACC/DEC
#1 to 7 to 1: Forward run, #2 ACC/DEC 0 8-28
F/R, ACC/DEC 2: Reverse run, #1 ACC/DEC
3: Reverse run, #2 ACC/DEC
Preset Functions Required To Perform the Pattern Run
Reverse run
Forward run
0
Output frequency
