6.5 Program Function Access/Set - Status Keys (Cont'd)
Key Function
"5" is the numerical five.
1st FUNCTION MODE: Sets output frequencies (F-P1, F-P2) based upon
percent of terminal IV input signal. Also sets the
percent of the terminal IV input signal (P1, P2).
Selects option for IV or RR terminal input to be on.
*2nd FUNCTION MODE: Selects option of TG/PG or PID to be on or off.
Sets proportional gain, integration gain,
differential gain, lag time constant, and
TG/PG feedback gain.
Selects PG feedback control options.
(* Optional board required for TG/PG selection.)
"6" is the numerical six.
1st FUNCTION MODE: Sets the jog run drive frequency.
Selects the jog run stop control options.
Sets the 1st~7th speed run frequencies.
2nd FUNCTION MODE: Sets the PWM carrier frequency.
"7" is the numerical seven.
1st FUNCTION MODE: Sets the jump frequencies (1, 2, 3) and the (1, 2, 3)
jump frequency band widths.
2nd FUNCTION MODE: Selects communication options (See Table 1 pg.
6-12), selects identification # for the inverter, selects
communication baud rate, selects parity check and
stop bit (See Table 2 pg. 6-12), and selects inverter
to AC line transfer signal to be on or off.
"8" is the numerical eight.
1st FUNCTION MODE: Selects how the multi-function I/O terminals will be
used.
2nd FUNCTION MODE: Selects the pattern run activation mode, units of
time, number of cycles.
Sets pattern drive time for Pt.1t~Pt.7t and selects
thepattern drive characteristics for the pattern run
(i.e.FOR or REV, ACC/DEC 1 or 2).
"9" is the numerical nine.
1st FUNCTION MODE: Selects FOR or REV run, selects trip retention on or
off option, selects retry (auto-reset) on or off option,
selects auto-restart after momentary power interrupt
on or off option, and selects regeneration power ride
through control on or off option.
2nd FUNCTION MODE: Selects eight command mode options, selects
eight frequency reference setting mode options,
and selects four parameter setting mode options.
