9.2 Recommended Spare Parts (Cont'd)
INVERTER PCB3 PCB 4-4B PCB5 PCB 6-6E PCB7 FU R,S,T
FAN FOR FAN FOR
MS1 MSX
UNIT
TOUCH PAD SNUBBER PA-PB G-E CKT G-E CKT AC CABINET HEAT SINK CONTACTOR RELAY
SNUBBER FUSE
QTY1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 1 QTY 1 NOT
G2+4110 35751A/ USED USED USED USED USED
38552A * A050F040 * 113XN0181 113XN0181 JH1a30A
QTY 1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 2 QTY 1 NOT
G2+4160 35751A/ USED USED USED USED USED
38552A * A050F060 * 113XN0181 113XN0181 PC-5
QTY 1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 2 QTY 1 NOT
G2+4220 35751A/ USED USED USED USED
38552A * A050F080 * 113XN0181 113XN0181 PC-5 USED
QTY 1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+4270 35751A/ USED USED USED USED
38552A * A050F080 * 129XR0281 129XR0281 C20A JC1a-10A
QTY 1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+4330 35751A/ USED USED USED USED
38552A * A050F100 * 129XR0281 129XR0281 C25A JC1a-10A
QTY 1 NOT NOT NOT NOT ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+4400 35751A/ USED USED USED USED
38552A * A050F150 * 129XR0281 129XR0281 C25A JC1a-10A
QTY 1 NOT QTY 1 NOT QTY 1 ** QTY 3 QTY 1 QTY 1 QTY 1 QTY 1
G2+4500 35751A/ USED USED
38552A 34499A 34557A * A050F150 * 129XR0281 148VK0281 C25A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1+1 QTY 2 QTY 1 QTY 1
G2+4600 35751A/ * 129XR0281
38552A 35081A 34499A 35249A 34557A * A050F200 113XN0181 148VK0281 C35A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1+1 QTY 2 QTY 1 QTY 1
G2+4750 35751A/ * 129XR0281
38552A 35081A 34499A 35249A 34557A * A050F200 113XN0181 148VK0281 C50A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+410K 35751A/
38552A 35081A 34499A 35249A 34557A * A050F300 129XR0281 148VK0281 C80A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+412K 35751A/
38552A 34465A 34499A 34558A 34557A * A050F300 129XR0281 148VK0281 C100A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1 QTY 2 QTY 1 QTY 1
G2+415K 35751A/
6.6-BODK-CA-
38552A 34465A 34499A 34558A 34557A
URB-31TTC-400
129XR0281 148VK0281 C125A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1 QTY 4 QTY 1 QTY 1
G2+420K 35751A/
6.6-BODK-CA-
38552A 34465A 34499A 34559A 34557A
URB-31TTC-500
148VK0281 148VK0281 C180A JC1a-10A
QTY 1 QTY 3 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 2 QTY 4 QTY 1 QTY 1
G2+425K 35751A/
6.6-BODK-CA-
38552A 34465A 34499A 34559A 34557A
URB-31TTC-630
148VK0281 148VK0281 C220A Jc1A-10A
QTY 1 QTY 6 QTY 1 QTY 6 QTY 1 ** QTY 3 QTY 1 QTY 1 QTY 1 QTY 1
G2+430K 35751A/
6.6-URD32-
McLean
38552A 34465A 34499A 38383A 34557A
TTF0800
148VK0281 4B1212-230 C220A Jc1A-10A
See notes on page 9-6
RANK B B B B B A A A B B
