TABLE OF CONTENTS
12
LED indicators:
Power
Internet
WiFi
LTE
WiFi Antenna Port 1
LTE Antenna Port 1
(Lock 500i only)
Ethernet Port Leds:
LAN2
WAN
LAN3
LAN1
WiFi Antenna Port 2
LTE Antenna Port 2
(Lock 500i only)
LOCK 500/500i
SIM card slot
USB Port
(for matching
and USB-modem)
Digital I/O -Connection
Ethernet Connections:
WAN Port
LAN2 Port
LAN1 Port
LAN3 Port*
Power Connection
* LAN3 Port can be configured as a Service port
