49
TABLE OF CONTENTS
LOCK 100
Ports
1x USB 2.0, type A, 500 mA maximum load allowed•
1 x RJ-45 WAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
3 x RJ-45 LAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
1 x RJ-45 Service conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
WAN connection features
Independent of operating systems•
Works in all Internet connections (operator independent)•
Firewall friendly•
Works with dynamic, static and private IP addresses•
Built-in firewall, NAT•
Up to 10 concurrent VPN connections•
VPN throughput up to 6 Mb/s (BF-CBC 128 bit)•
Physical properties
132 mm (L) x 99 mm (W) x 36 mm (H)•
Weight 365 g•
Operating temperature -25 °C … +70 °C•
Oparating humidity 20 - 80% RH, non condensing•
Storage temperature -40 °C … +70 °C•
Cast aluminium casing•
IP protection class: IP20 •
Maximum operating altitude 2000 m •
Overvoltage category I•
USB modem options
TB4GM2EU, for 3rd party options, •
please see: http://www.tosibox.com/support
WLAN
IEEE 802.11 b/g/n, max. 150 Mbps•
WEP, WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK Mixed, WPA-EAP, •
WPA2-EAP TKIP/AES encryption
Frequency 2.412 – 2.462 GHz, 11 channels
•
Output power 20 dBm max•
Powering requirements
Lock 100: 8-30V DC (absolute value), 7.2W max, reverse polarity •
protected
11. TECHNICAL DATA
11.1 TOSIBOX
®
LOCKS
