LOCK 200
Ports
1x USB 2.0, type A, 500 mA maximum load allowed•
1 x RJ-45 WAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
3 x RJ-45 LAN conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
1 x RJ-45 Service conn., 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
WAN connection features
Independent of operating systems•
Works in all Internet connections (operator independent)•
Firewall friendly•
Works with dynamic, static and private IP addresses•
Built-in firewall, NAT•
Up to 50 concurrent VPN connections•
VPN throughput up to 15 Mb/s (BF-CBC 128 bit)•
Physical properties
140 mm (L) x 36 mm (W) x 125 mm (H)•
Weight 530 g•
Operating temperature -20 °C … +50 °C•
Operating humidity 20 – 80% RH, non condensing•
Storage temperature -40 °C … +70 °C•
Cast aluminium casing•
IP protection class: IP20•
Maximum operating altitude 2000 m•
Overvoltage category I•
USB modem options
TB4GM2EU, TB4GM2AU, for 3rd party options, please see: •
http://www.tosibox.com/support
Powering requirements
Lock 200: 8-27V DC +/-10%, 7.0W max, reverse polarity protected•
