51
TABLE OF CONTENTS
Physical properties
110 mm (L) x 58 mm (W) x 127 mm (H)•
Weight 495 g (TBL5*) / 505g (TBL5i*)•
Operating temperature -20 °C … +70 °C (TBL5*) / -20 °C … +60 °C •
(TBL5i*)
Operating humidity up to 96% RH, non-condensing
•
Storage temperature -40 °C … +70 °C•
Cast aluminium casing•
IP protection class: IP20•
Maximum operating altitude 2000 m •
Overvoltage category I•
USB modem options
TB4GM2EU, TB4GM2AU•
Internal modem connection features
TBL5iA*•
Region: Americas/EMEA•
LTE Cat-6•
Up to 300 Mbps DL, 50 Mbps UL•
Frequency Bands (4G LTE): B1, B2, B3, B4, B5, B7, B12, B13, B20, B25, •
B26, B29, B30, B41
Supported technology (HSPA+, UMTS) Bands: B1, B2, B3, B4, B5, B8•
Dual SIM•
LOCK 500
Ports
1x USB 2.0, type A, 500 mA maximum load allowed•
1 x RJ-45 WAN connection, 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
3 x RJ-45 LAN connection, 10/100 Mb/s, auto-negotiation (MDI / MDI-X)•
LAN3 can be assigned as Service connection, 10/100 Mb/s, auto-negotiation •
(MDI / MDI-X)
Ethernet port isolation: 1500 Vrms 1 minute (when connected to protective
•
ground)
WAN connection features
Independent of operating systems•
Works in all Internet connections (operator independent)•
Supports HTTP proxy servers with and without authentication•
Firewall friendly•
Works with dynamic, static and private IP addresses•
Built-in firewall, NAT•
Up to 50 concurrent VPN connections•
VPN throughput up to 90 Mb/s (BF-CBC 128 bit)•
