Tosibox Lock 500 User Manual

TABLE OF CONTENTS
52
WCDMA frequency bands support
Band
1
Frequency (Tx) Frequency (Rx)
Band 1 1920–1980 MHz 2110–2170 MHz
Band 2 1850–1910 MHz 1930–1990 MHz
Band 3 1710–1785 MHz 1805–1880 MHz
Band 4 1710–1755 MHz 2110–2155 MHz
Band 5 824–849 MHz 869–894 MHz
Band 8 880–915 MHz 925–960 MHz
1.WCDMA channel spacing is 5 MHz, but this can be adjusted to optimize
•
perfor-mance in a particular deployment scenario.
Conducted TX (Transmit) Power tolerances
Parameter Cond. tr. p. Notes
LTE
LTE Band 1, 3, 5, 8, 18,
19,21,28,39 +23 dBm +- 1 dB
LTE Band 7, 38, 40, 41 +22 dBm +- 1 dB
UMTS
Band 1 (IMT 2100 12.2 kbps)
Band 5 (UMTS 850 12.2 kbps)
Band 6 (UMTS 850 12.2 kbps) +23 dBm +- 1 dB Connectorized (Class 3)
Band 8 (UMTS 900 12.2 kbps)
Band 9 (UMTS 1700 12.2 kbps)
Band 19 (UMTS 850 12.2 kbps)
LTE frequency band support
Band Frequency (Tx) Frequency (Rx)
Band 1 1920–1980 MHz 2110–2170 MHz
Band 2 1850–1910 MHz 1930–1990 MHz
Band 3 1710–1785 1805–1880 MHz
Band 4 1710–1755 2110–2155 MHz
Band 5 824–849 MHz 869–894 MHz
Band 7 2500–2570 MHz 2620–2690 MHz
Band 8 880–915 MHz 925–960 MHz
Band 12 699–716 MHz 729–746 MHz
Band 13 777–787 MHz 746–756 MHz
Band 20 832–862 MHz 791–821 MHz
Band 25 1850–1915 MHz 1930–1995 MHz
Band 26 814–849 MHz 859–894 MHz
Band 29 n/a 717–728 MHz
Band 30 2305–2315 MHz 2350–2360 MHz
Band 41 2496–2690 MHz (TDD)
For bandwidth support details, see 3GPP TS 36.521-1 v11.3.0, table 5.4.2.1-1
•
