53
TABLE OF CONTENTS
TD-SCDMA
Band 39 +23 dBm +- 1 dB
Internal modem connection features (Continues)
TBL5iB*
Region: APAC
•
LTE Cat-6•
Up to 300 Mbps DL, 50 Mbps UL•
Frequency Bands (4G LTE): B1, B3, B5, B7, B8, B18, B19, B21, B28, B38, B39, •
B40, B41
Supported technology 1 (HSPA+, UMTS) Bands: B1, B5, B6, B8, B9, B19•
Supported technology 2 (TD-SCDMA) Band 39•
Dual SIM•
LTE frequency band support
Band Frequency (Tx) Frequency (Rx)
Band 1 1920–1980 MHz 2110–2170 MHz
Band 3 1710–1785 1805–1880 MHz
Band 5 824–849 MHz 869–894 MHz
Band 7 2500–2570 MHz 2620–2690 MHz
Band 8 880–915 MHz 925–960 MHz
Band 18 815–830 MHz 860–875 MHz
Band 19 830–845 MHz 875–890 MHz
Band 21 1447.9–1462.9 MHz 1495.9–1510.9 MHz
Band 28 703–748 MHz 758–803 MHz
Band 38 2570–2620 MHz (TDD)
Band 39 1880–1920 MHz (TDD)
Band 40 2300–2400 MHz (TDD)
Band 41 2496–2690 MHz (TDD)
For bandwidth support details, see 3GPP TS 36.521-1 v11.3.0, table 5.4.2.1-1
•
WCDMA frequency bands support
Band
a
Frequency (Tx) Frequency (Rx)
Band 1 1920–1980 MHz 2110–2170 MHz
Band 5 824–849 MHz 869–894 MHz
Band 6 830–840 MHz 875–885 MHz
Band 8 880–915 MHz 925–960 MHz
Band 9 1749.9–1784.9 MHz 1844.9–1879.9 MHz
Band 19 830–845 MHz 875–890 MHz
a. WCDMA channel spacing is 5 MHz, but this can be adjusted to optimize
performance in a particular deployment scenario.
TD-SCDMA Frequency Bands
Band Frequency range
Band 39 1880–1920 MHz
