tousek PULL T24 - Page 16

- 16 - tousek / E_PULL-T24-T24speed_49002410 / 06. 08. 2019
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
1 2
+ -
~ ~
12/24V
1 2 3 4 5
+ -
~ ~
12/24V
46
45
43
41
40
transmitter 1 receiver 1
receiver 2 transmitter 2
-
-
+
NO NC COM
NO NC COM
Deactivation of SYNC function
• The SYNC function with LS41 is
not possible with this control unit.
For deactivation of SYNC function,
the jumpers J of both transmitters
have to be connected (see picture).
(see manual LS41)
SYNC
J
2 Photocells Tousek LS 41 as safety device
transmitter 1 receiver 1
receiver 2 transmitter 2
Photocell Tousek LS 41 as safety device
transmitter receiver
2 Photocells Tousek LS 45/2 as safety device Photocells Tousek RLS 610 as safety device
-
-
+
46
45
43
41
40
24–230V
a.c./d.c.
24Vd.c.
COM
NO
NC
COM
-
-
+
N.O. COM N.C.
46
45
43
41
40
N.O. COM N.C.
-
-
+
N.O. COM N.C.
46
45
43
41
40
