tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020 - 15 -
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contactscan be used.
Pedestrian opening button (terminals
M
30/34)
M
Buttons / switches
OPEN/ STOP / CLOSE impulse repetition: An impulse through the pedestrian button-while the gate is in motion-
causes gate stopping. If the gate is within the pedestrian area, then an impulse through the pedestrian button causes
inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE di-
rection and the gate stopps at pedestrian OPEN position.
OPEN / CLOSE / OPEN impulse repetition:
If the gate is within the pedestrian area, then an impulse through the
pedestrian button causes inversion of the direction.
If the gate is in complete open position an impulse through the pedestrian button causes a movement in CLOSE direction
and the gate stopps at pedestrian OPEN position.
• In this operation mode it is not possible to stop the motor with the pedestrian button – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the pedestrian opening button. Closing the pedestrian entry with the
button is not possible.
DEADMAN (not selectable): As soon as the Impulse button is set to DEADMEN, automatically the pedestrian- and the
CLOSE button are set to DEADMEN.
The motor opens as long as the pedestrian button is pressed – closing the gate with the pedestrian button is not
possible. As soon as the switch is released, the gate stops.
As CLOSE-buttons you may use pushbuttons or key switches as well as external radio receivers with potential
free make contacts can be used.
CLOSE-button (terminals
M
30/33) Buttons / switches
• A command with the CLOSE-switch engages closing of gate. In deadman mode the gate closes as long as the
CLOSE-switch is pressed/switched. As soon as switch is released the gate movement stops.
STOP-switch (terminals
M/S
31/37) Buttons / switches
• when pressing the stop switch the gate stops in any desired position.
As stop switch a break contact has to be used.
If no stop switch is connected, terminals 31/37 have to be wire-bridged.
37
31
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide
the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation!
