- 20 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Attention
With force adjustment the valid safety regulations and standards have to be strictly followed !
max. force 70% (factory setting)
M/S
Motor
25–100% adjustable [increment 5]: determines the max. possible motor force.
ARS response time 0,50s (factory setting)
M/S
Motor
0,15–0,95s adjustable [increment 0,05]: determines, in which time the AR-System responds. The lower the value,
the more sensitive the sensor will react.
Speed 100% (factory setting)
M/S
Motor
65–100% adjustable [increment 5]: determines the speed of motor.
Soft stop distance 0,5m (factory setting)
M/S
Motor
0–2m adjustable [increment 0,1]: determines the distance of soft run.
Soft stop speed 50% (factory setting)
M/S
Motor
30–60% adjustable [increment 5]: determines the speed during soft run.
End position OPEN -5 (factory setting)
M/S
Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected OPEN limit position of gate (e.g. for
safety sensing edges). With adjustment 0 the motor runs to the previously learned open position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
End position CLOSED -5 (factory setting)
M/S
Motor
0...-30 adjustable [increment 1]: for readjustment of the automatically detected CLOSE limit position of gate (e.g.
for safety sensing edges. With adjustment 0 the motor runs to the previously learned close position.
For a diminished drive distance the value can be extended to up to -30.
This adjustment is ONLY adopted in CLOSED-position.
Motor Connections and adjustments
