• Before taking o the control cover, the
mains switch must be turned o!
• If the control is power supplied, its inner part is under
tension.
• In order to avoid electrical strokes, the safety regula-
tions have to be kept.
• The device may only be connected by trained profes-
sionals.
• The product is not suitable for installation in explosion-
hazardous areas.
• An all-pole disconnecting mains switch with a contact
opening gap of min. 3 mm has to be foreseen. The
gate facility has to be secured according to the valid
safety regulations!
• IMPORTANT: The control lines (buttons, radio, pho-
tocells, etc.) have to be laid separately from the 230V
lines (supply line, motors, signal lamp).
Warning notes
• A general status display of all inputs can be found in the menu DIAGNOSIS / STATUS DISPLAY
3.3 Connections and adjustments PULL T8, -T10, -T15 / Master-Slave
The dierent menu points, that can be selected in the Master control board (=
M
) or in the Master and in the
Slave control board (=
M/S
) are indicated as follows:
= selectable setting (or possible value assignment) = factory settings = status display
G
shows the menu points which are in the “ BASIC SETTINGS” of the Master control board
Furthermore connection notes and other instructions are indicated as follows
M
= regards the Master control board
M/S
= regards the Master ans Slave control board
As impulse emitters pushbuttons or key switches as well as external radio receivers with potential free make
contacts can be used.
Impulse switch (terminals
M
30/32)
M
Buttons/switches
OPEN/ STOP / CLOSE impulse repetition (factory settings): After a command of the impulse switch the motor starts
an open or close movement. If the impulse switch is pressed again during this movement, the motor stops. With the
next command, the motor drives in the opposite direction of the last gate movement.
OPEN / CLOSE / OPEN impulse repetition: After a command of the impulse switch the motor starts an open or close
movement. If the impulse switch is pressed again during this movement, the motor reverses.
• In this operation mode it is not possible to stop the motor with the impulse switch – it always
travels until reaching an end position. (Opened or closed position).
• for the function OPEN/CLOSE/OPEN we strongly suggest the installation of a photocell!
OPEN: Only open commands are accepted of the impulse switch. Closing the gate with the impulse switch is not
possible.
DEAD-MAN: The motor opens as long as the impulse switch is pressed – closing the gate with the impulse switch
is not possible. As soon as the switch is released, the gate stops. If hold to run operating mode is selected, the radio
receiver slot (FE) is set out of order for reasons of safety.
IMPORTANT: Do not put into operation in dead man mode.
Select only after putting into operation (see page 27), if desired.
