tousek PULL T8 - Diagnosis

- 24 - tousek / EN_PULL-T8-T10-T15-M-S_02 / 25. 03. 2020
Note: The factory settings of the
single menu points are marked
with  in this manual.
The mechanical stops have to be placed so
that possibly existing safety contact edges
can not be triggered, as this would lead to
an error message.
Status display
M/S
Diagnosis
 Status display for inputs as photocell, safety sensing edges, stop button, impulse switch ....
I Impulstaster
P pedestrian entry
C CLOSE-button
S STOP-button
Ph photocell contact
ME main safety edge
SE side safety edge
Delete positions
M
Diagnosis
 NO: does not delete the end positions “gate closed”
and “gate open”
 YES: the determined end positions are beeing deleted.
Note: the end positions will be determined after new impulse.
Factory settings
M
Diagnosis
 NO: No reset back to factory settings
 YES: Reset back to factory settings
Software version
M/S
Diagnosis
 Shows the software version on display
Serial number
M/S
Diagnosis
 Shows the serial number on display
Protocol
M/S
Diagnosis
 Shows the protocol list on display: all events that take place are protocolled in this list.
with the buttons + and - the single events can be seen:
Status Sensor
M/S
Diagnosis
 Degree and signal strenght of rotation speed sensor is shown on display.
All inputs okay.
e.g.
Diagnosis Connections and adjustments
$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
T -00 00:00:00.0
Event
With
*
the protocole beginning
hence the end is shown
Type of event
Time since the last event:
DAYS HOURS: MINUTES : SECONDS
If for any reason ONLY ONE of the two control board is replaced, the rst thing to do is to select
„Delete positions“ in the menu point „Diagnosis“, otherwise a fatal system crash may occur!
$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
I P C S Ph ME SE$$$$$$$$$$$$$$$$
$$$$$$$$$$$$$$$$
I P C S Ph ME SE
Impulse-, pedestrian - and close button not triggered.
STOP-button and photocell are triggered.
Contact strip (main closing edge) not connected or defect.
contact strip (side closing edge) triggered.
$
Status: not triggered
$-
Status: triggered
$x
Status: contact strip not connected or defect
$o
Status: contact strip or photocell deactivated in menu
