Toyota 8FDU32 User Manual

SECTION INDEX
NAME
SECTION
GENERAL
0
ENGINE - CHASSIS
1
4Y-E REPAIR
1.1
1DZ-II REPAIR
1.2
4Y-E LPG DEVICE REPAIR
1.3
TRANSMISSION (Pn1•2•3 / Cu2•3)
2
TRANSMISSION (Cu1 Ton Series)
2.1
PROPELLER SHAFT
3
DIFFERENTIAL
4
FRONT AXLE
5
REAR AXLE
6
STEERING
7
BRAKE
8
BODY
9
MATERIAL HANDLING SYSTEM
10
MAST
11
CYLINDER
12
OIL PUMP
13
OIL CONTROL VALVE
14
MINI LEVER - JOYSTICK
15
SAS / OPS
16
SSTLIST - SERVICE STANDARDS LIST
17
MULTIFUNCTION DISPLAY DX (OPTIONAL)
18
ELECTRICAL SYSTEM TROUBLESHOOTING [except Cu1]
19
ELECTRICAL SYSTEM TROUBLESHOOTING [Cu1 ton series]
19.1
WIRING DIAGRAM
E
SERVICE INFORMATION BULLETINS SIB

Toyota 8FDU32 Specifications

General

Model	8FDU32
Fuel Type	Diesel
Transmission	Automatic
Tire Type	Pneumatic
Rated Capacity	3200 kg
Load Capacity	3200 kg
Load Center	500 mm
Lift Height	3000 mm
Mast Type	Triple
Overall Length	2470 mm
Overall Width	1150 mm
Overall Height	2070 mm
