Archer C55
AC1200 Wireless Dual Band Gigabit Router
- 8 -

Note:
If the 2.4GHz LED and 5GHz LED are off, please press the Wi-Fi On/Off button on the rear panel
for 2 seconds, then the LEDs should be on in a few seconds.
Please follow the steps below to mount the router to the wall if you need.
105
∅8
∅3.5
2.5 1.2
ØD
X
X>=20mm

Note:
The diameter of the screw ranges from 3.5 mm to 8 mm, and the distance between two screws is
105 mm. The screw that projects from the wall needs around 4.5 mm base, and the length of the
screw needs to be at least 20 mm to withstand the weight of the product.
